F-Series Telescopic Semi-Electric Stacker

F-Series Telescopic Semi-Electric Stacker

Product Description

watch-video

download_product_btn    parts_breakdown_btn

SKU: F-Series Category:

Overview

The Mobile F-Series Telescopic Stacker is perfectly suited for high reach, tight space applications. Equipped with power lift and easy to maneuver manual push/pull, the FTAFC96 is designed to lift a variety of loads via adjustable straddle legs, is perfect for racking and shelving applications as well as loading/unloading trucks where docks do not exist.

Specifications

  • Capacity : 1,500 lbs
  • Overall Length : 78″
  • Fork Length : 42″
  • Forks Adjust : 8-25″
  • Straddle Legs I.D. : 36″ – 50″
  • Straddle Legs O.D. : 42″ – 56″
  • Lowered Fork Height : 3″
  • Raised Fork Height : 96″ / 120″ / 132″ / 144″
  • Raised Mast Height : 118″ / 142″ / 154″ / 166″
  • Lowered Mast Height: 70″ / 82″ / 88″ / 94″
  • Weight : 815 / 875 / 900 / 924 lbs
  • Steer Wheel : 7″
  • Load Rollers : 4″
  • Formed Channel Steel Construction
  • Adjustable Forks/Straddle Legs
  • 6:1 Safety Factor Ensuring Safe Fork Lowering
  • Steel Safety Screen
  • On Dash Lever For Lifting & Lowering
  • Rebuilable Pump for Easy Seals/Wiper Replacement
  • Hand Controlled Floor-Lock Brake
  • High-Quality Powder Coat Paint Finish
